HP Z2 Small Form Factor G9 Workstation
Get all the power of a full size tower at a fraction of the size. Re-engineered to fit full-height, full-length graphics while leaving room for upgrades and expansion, the Z2 SFF delivers high performance for your intensive workflow—from 3D design to real time ray tracing—now and in the future.
Key Features
- Full height, full length performance: Design, simulate and—for the first time—real time ray trace on a Z2 SFF. Now fitting full height, full length professional graphics and Intel® processors, this PC delivers tower-sized performance that defies space constraints
- Configurable for today. Expandable for tomorrow.: Accelerate your current workflow with a multitude of options across processor, graphics, memory, storage, and I/O ports with plenty of room to upgrade and expand
- ISV Certified: Work with confidence knowing your PC is certified with leading software applications to ensure peak performance.[3]
Specifications 66
| UPC number | 198122822188 |
| Product long name specifications | HP Z2 Small Form Factor G9 Workstation, Windows 11 Pro, Intel® Core™ i7, 32GB RAM, 512GB SSD, RTX™ A2000, AI Workstation |
| Product short name specifications | HP Z2 Small Form Factor G9 Workstation, Intel® Core™ i7, 32GB RAM, 512GB SSD, AI Workstation |
| UNSPSC code | 43211515 |
| Power | 450 W 90% efficient, wide-ranging, active PFC |
| Ecolabels | EPEAT® registered |
| Energy star certified | ENERGY STAR® certified |
| Expansion slots | 1 half-height PCle 4 x16; 1 half-height PCle 3 x4; 1 half-height PCle 3 x4 (x16 connector); 1 half-height PCle 3 x1; 1 full-height PCle 4 x16; 1 full-height PCle 4 x16 (x16 connector) |
| Expansion slots note | 1 M.2 2230 slot for WLAN and 3 M.2 2280 slots for storage |
| Ports | 1 SuperSpeed USB Type-C® 20Gbps signaling rate (USB Power Delivery, DisplayPort™ 1.4, HP Sleep and Charge); 4 SuperSpeed USB Type-A 10Gbps signaling rate (1 charging); 1 universal audio jack |
| I/O Port location | Front |
| Ports | 3 USB Type-A 5Gbps signaling rate; 2 DisplayPort™ 1.4; 1 RJ-45; 1 audio-in; 1 audio-out; 1 HP Fiber NIC Port Flex IO; 3 USB Type-A 480Mbps signaling rate |
| I/O Port location | Rear |
| Network interface | Intel® I219-LM GbE |
| Dimensions (W x D x H) | 38.4 x 30.8 x 10 cm |
| Dimensions (W x D x H) Note | Standard desktop orientation. |
| Package dimensions (W x D x H) | 10 x 38.4 x 30.8 cm |
| Package dimensions (W x D x H) | 3.95 x 15.1 x 12.1 in |
| Dimensions (W x D x H) | 15.1 x 12.1 x 3.95 in |
| Dimension note (imperial) | Standard desktop orientation. |
| Compatible displays | All HP Z Displays and HP DreamColor Displays are supported. For more information see www.hp.com/go/zdisplays |
| Compatible displays note | Supports 8 displays, driving 8 displays requires the use of integrated and discrete graphics ports. Each source can drive a total of 4 displays. At least one of the integrated graphics ports need to drive two displays in a daisy chain configuration. |
| External drive bays | One 3.5" HDD; One slim ODD |
| Internal drive bays | One 2.5" HDD; One 3.5" HDD; Three M.2 NVME 2280 SSD |
| Internal Storage | 512 GB HP Z Turbo Drive PCIe® NVMe™ TLC M.2 SSD |
| Storage controller | Integrated SATA (4 ports 6 Gb/s) with integrated RAID 0, 1, for PCIe SSDs supported. Requires identical hard drives (speeds, capacity, interface). |
| Energy Usage CO2e (kg) | 306 |
| Sustainable impact specifications | 80 Plus® Gold power supplies available; 25% ITE-derived closed loop plastic; Bulk packaging available; Molded paper pulp cushion inside box is 100% sustainably sourced and recyclable; 45% post-consumer recycled plastic; 10% ITE-derived closed loop plastic; Ocean-bound plastic in speaker enclosure and system fan; Low halogen PCAs; Product Carbon Footprint; Ocean-bound plastic in system fan, processor fan and speaker |
| End of Life CO2e (kg) | 2 |
| Production CO2e (kg) | 209 |
| Total CO2e (kg) | 520 |
| Total CO2e (kg) note | A product carbon footprint is defined as the total amount of greenhouse gases emitted directly and indirectly by a product over its lifetime. Greenhouse gas emissions are reported as global warming potential for 100-year time horizon (GWP-100) in units of CO2 equivalence. Calculations are done in accordance with ISO 14040 & ISO 14044. Individual values may not sum to total due to rounding. |
| Transportation CO2e (kg) | 2 |
| Graphics (integrated) | Intel® UHD Graphics 770 |
| Graphics | Integrated |
| Graphics (discrete) | NVIDIA RTX™ A2000 (12 GB GDDR6 dedicated) |
| Graphics | Discrete |
| Memory layout (slots & size) | 1 x 32 GB |
| Memory | 32 GB DDR5-4800 MT/s (1 x 32 GB) |
| Standard memory note | Transfer rates up to 4800 MT/s. |
| Memory and storage | 32 GB memory; 512 GB SSD storage |
| Audio | Realtek ALC3252 |
| Keyboard | HP USB 320K Keyboard |
| Pointing device | HP Wired 320M Mouse |
| Chipset | Intel® W680 |
| Processor cache | 33 MB L3 cache |
| Processor core | 16 |
| Processor family | Intel® Core™ i7 14th generation processor |
| Processor | Intel® Core™ i7-14700 (up to 5.4 GHz with Intel® Turbo Boost Technology, 33 MB L3 cache, 20 cores, 28 threads) |
| Security management | HP Secure Erase; HP Sure Click; HP BIOSphere Gen6; HP Sure Admin; Hood Sensor Optional Kit; HP Client Security Manager Gen6; HP Sure Start Gen7; HP Sure Recover Gen4; HP Tamper Lock; HP Sure Sense Gen2; HP Sure Run Gen5 |
| Security Software Licenses | HP Wolf Pro Security Edition (1 year) |
| Security software licenses footnote number | [56] |
| Management features | HP Client Catalog (download); HP Cloud Recovery; HP Driver Packs; HP Management Integration Kit for Microsoft System Center Configuration Management Gen4; HP System Software Manager (download); HP BIOS Configuration Utility (download); HP Image Assistant (download); HP Client Management Script Library (download) |
| Software included | HP PC Hardware Diagnostics UEFI; HP Support Assistant; HP PC Hardware Diagnostics Windows; HP Privacy Settings; HP Desktop Support Utilities; HP Image Assistant; HP Manageability Integration Kit; HP Notifications; Performance Advisor 3.0; HP Data Science Stack Manager; myHP |
| Software included | HP Documentation |
| Software included | WPS Office |
| Software included | Touchpoint Customizer for Commercial |
| Software included | HP UWP Pack |
| Operating system | Windows 11 Pro |
| Manufacturer Warranty | 3 year (3/3/3) limited warranty includes 3 years of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
| Weight | Starting at 5.0 kg |
| Weight note (metric) | Exact weights depend upon configuration (System weight only) |
| Package weight | Starting at 5.9 kg |
| Package weight | Starting at 13.1 lb |
| Weight | Starting at 11.1 lb |
| Weight note (imperial) | Exact weights depend upon configuration (System weight only) |
