Reference Only
HP Z2 Mini G9 Workstation
Tackle workflows you never thought before possible on such a tiny PC. The HP Z2 Mini easily fits on your desk or behind your monitor so you can tackle 3D projects without losing valuable office space. All while feeling protected From the BIOS to the browser, above, in, and below the OS with HP Wolf Security Suite.
Key Features
- Unprecedented Z mini power[2]: Now, get standard low-profile graphics in a Z2 Mini, combined with Intel© Core™ processors, for seamless design, rendering and simulation
- Fits anywhere: Create your ideal workspace whether you're working in an office or at home. With a versatile design, set it on your desk, mount it behind your monitor or attach it under your desk.[3]
- Engineered to Evolve with your workflow: This mini evolves with your workflow. Its slide-out design gives tool-free interior access so you can easily swap graphics and memory. Easily connect peripherals with plenty of I/O ports
- Industry leading security. Reliability you can trust: Get peace of mind with a PC that's built to endure. The Z2 Mini undergoes 360K hours of rigorous testing, military-standard testing[5] and is certified for pro apps.
Specifications 74
| UPC number | 198122696925 |
| Product long name specifications | HP Z2 Mini G9 Workstation, Windows 11 Pro, Intel® Core™ i7, 16GB RAM, 512GB SSD, NVIDIA® T1000 |
| Product short name specifications | HP Z2 Mini G9 Workstation, Intel® Core™ i7, 16GB RAM, 512GB SSD |
| UNSPSC code | 43211515 |
| Power | 280 W external power adapter, up to 90% efficiency, active PFC |
| Ecolabels | EPEAT® registered |
| Energy star certified | ENERGY STAR® certified |
| Expansion slots | 2 M.2 2280 PCIe 4 x4; 1 M.2 2230 for WLAN; 1 PCIe® 4 x8 (PCIe Low Profile connector) |
| Ports | 1 headphone/microphone combo; 1 SuperSpeed USB Type-A 10Gbps signaling rate (1 charging); 2 SuperSpeed USB Type-C® 20Gbps signaling rate |
| I/O Port location | Side |
| Ports | 1 RJ-45; 2 DisplayPort™ 1.4; 3 SuperSpeed USB Type-A 10Gbps signaling rate |
| I/O Port location | Rear |
| Network interface | Intel® I219-LM GbE |
| Wireless | Intel® Wi-Fi 7 BE200 (2x2) and Bluetooth® 5.4 wireless card, non-vPro® |
| Dimensions (W x D x H) | 21.1 x 21.8 x 6.9 cm |
| Dimensions (W x D x H) Note | Standard desktop orientation. |
| Package dimensions (W x D x H) | 49.9 x 17.0 x 29.8 cm |
| Package dimensions (W x D x H) | 19.6 x 6.7 x 11.7 in |
| Dimensions (W x D x H) | 8.3 x 8.6 x 2.7 in |
| Dimension note (imperial) | Standard desktop orientation. |
| Compatible displays | HP Z34C, Z40C, Z27Q G3, Z27K, and Z27XS G3 4k. All HP Z Displays and HP DreamColor Displays are supported. For more information see http://www.hp.com/go/zdisplays |
| Compatible displays note | Supports 8 displays, driving 8 displays requires the use of integrated and discrete graphics ports. Each source can drive a total of 4 displays. At least one of the integrated graphics ports need to drive two displays in a daisy chain configuration. |
| Internal Storage | 512 GB HP Z Turbo Drive PCIe® NVMe™ TLC M.2 SSD |
| Energy Usage CO2e (kg) | 119 |
| Sustainable impact specifications | 80 Plus® Gold power supplies available; Bulk packaging available; Molded paper pulp cushion inside box is 100% sustainably sourced and recyclable; Outside box and corrugated cushions are 100% sustainably sourced and recyclable; 55% post-consumer recycled plastic; 15% ITE-derived closed loop plastic; Ocean-bound plastic in speaker enclosure and system fan; Low halogen PCAs; Product Carbon Footprint |
| End of Life CO2e (kg) | 1 |
| Production CO2e (kg) | 197 |
| Total CO2e (kg) | 320 |
| Total CO2e (kg) note | A product carbon footprint is defined as the total amount of greenhouse gases emitted directly and indirectly by a product over its lifetime. Greenhouse gas emissions are reported as global warming potential for 100-year time horizon (GWP-100) in units of CO2 equivalence. Calculations are done in accordance with ISO 14040 & ISO 14044. Individual values may not sum to total due to rounding. |
| Transportation CO2e (kg) | 1 |
| Graphics (integrated) | Intel® UHD Graphics 770 |
| Graphics | Integrated |
| Graphics (discrete) | NVIDIA® T1000 (4 GB GDDR6 dedicated) |
| Graphics | Discrete |
| Memory layout (slots & size) | 1 x 16 GB |
| Memory Slots | 2 SODIMM |
| Memory | 16 GB DDR5-5600 MT/s (1 x 16 GB) |
| Standard memory note | Transfer rates up to 5600 MT/s. |
| Memory and storage | 16 GB memory; 512 GB SSD storage |
| Audio | Realtek ALC3205-VA2-CG, 2.0W internal mono speaker |
| Keyboard | HP USB 320K Keyboard |
| Pointing device | HP Wired 320M Mouse |
| Processor cache | 33 MB L3 cache |
| Processor core | 20 |
| Processor family | Intel® Core™ i7 14th generation processor |
| Processor | Intel® Core™ i7-14700 (up to 5.4 GHz with Intel® Turbo Boost Technology, 33 MB L3 cache, 20 cores, 28 threads) |
| Security management | HP Secure Erase; HP Sure Click; HP BIOSphere Gen6; HP Sure Admin; Hood Sensor Optional Kit; HP Client Security Manager Gen6; HP Sure Start Gen7; HP Sure Recover Gen4; HP Tamper Lock; HP Sure Sense Gen2; HP Sure Run Gen5 |
| Security Software Licenses | HP Wolf Pro Security Edition (1 year) |
| Security software licenses footnote number | [56] |
| Management features | HP BIOS Configuration Utility (download) |
| Manageability Features 1 | High performance Mode |
| Manageability Features 10 | HP Driver Packs |
| Manageability Features 2 | Quite Mode |
| Manageability Features 3 | Rack Mode |
| Manageability Features 5 | HP Cloud Recovery |
| Manageability Features 6 | HP Client Catalog (download) |
| Manageability Features 7 | HP Image Assistant (download) |
| Manageability Features 8 | HP Client Management Script Library (download) |
| Manageability Features 9 | HP System Software Manager (download) |
| Software included | HP PC Hardware Diagnostics UEFI; HP Support Assistant; HP PC Hardware Diagnostics Windows; HP Privacy Settings; HP Desktop Support Utilities; HP Image Assistant; HP Manageability Integration Kit; HP Notifications; Performance Advisor 3.0; HP Data Science Stack; myHP |
| Software included | HP Easy Clean |
| Software included | HP Documentation |
| Software included | WPS Office |
| Software included | Touchpoint Customizer for Commercial |
| Software included | HP UWP Pack |
| Operating system | Windows 11 Pro |
| Form factor | Mini |
| Manufacturer Warranty | 1 year (1/1/1) limited warranty includes 1 year of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
| Weight | Starting at 2.4 kg |
| Weight note (metric) | Exact weight depends on configuration. |
| Package weight | Starting at 4.8 kg |
| Package weight | Starting at 10.6 lb |
| Weight | Starting at 5.29 lb |
| Weight note (imperial) | Exact weight depends on configuration. |
