HP Z2 Tower G9 Workstation
Experience a whole new level of performance for your professional workflow. The Z2 Tower is engineered to seamlessly run multi-threaded apps for fast rendering, simulation, and now real-time ray tracing. And when your demands change, you have impressive expandability to upgrade.
Key Features
- Your new benchmark for entry workstation power: Unleash the power of professional graphics and an Intel® Core™ processor on intensive multi-threaded apps. Designed for zero throttling so you can render, simulate, and even real-time ray trace without overheating or slow downs
- Built to expand. Power to grow: Need to upgrade graphics? Add specialized PCIe cards? With room to expand and tool-less access, you can add components as your needs evolve. This is an investment that will last
- ISV Certified: Work with confidence knowing your PC is certified with leading software applications to ensure peak performance[3]
Specifications 75
| UPC number | 198122822973 |
| Product long name specifications | HP Z2 Tower G9 Workstation, Windows 11 Pro, Intel® Core™ i7, 16GB RAM, 512GB SSD, RTX™ A2000, AI Workstation |
| Product short name specifications | HP Z2 Tower G9 Workstation, Intel® Core™ i7, 16GB RAM, 512GB SSD, AI Workstation |
| UNSPSC code | 43211515 |
| Power | 450 W 90% efficient, wide-ranging, active PFC |
| Ecolabels | EPEAT® registered |
| Energy star certified | ENERGY STAR® certified |
| Expansion slots | 1 PCIe 3 x4 (x16 connector); 1 PCIe 3 x4 (x4 connector); 1 PCIe 3 x1 (x4 connector); 1 PCIe 5 x16 (x16 connector); 1 M.2 2230 PCIe 3 X1 for WLAN |
| Expansion slots note | 1 M.2 2230 slot for WLAN and 3 M.2 2280 slots for storage |
| Ports | 4 SuperSpeed USB Type-A 10Gbps signaling rate (1 charging); 1 universal audio jack |
| I/O Port location | Front |
| Ports | 1 audio-in; 1 audio-out; 1 RJ-45; 2 DisplayPort™ 1.4; 2 SuperSpeed USB Type-A 10Gbps signaling rate; 1 SuperSpeed USB Type-A 5Gbps signaling rate; 3 USB Type-A 480Mbps signaling rate |
| I/O Port location | Rear |
| Network interface | Intel® I219-LM GbE |
| Dimensions (W x D x H) | 35.6 x 16.9 x 38.5 cm |
| Dimensions (W x D x H) Note | Standard tower orientation. |
| Package dimensions (W x D x H) | 51.8 x 29.5 x 49 cm |
| Package dimensions (W x D x H) | 20.39 x 11.61 x 19.29 in |
| Dimensions (W x D x H) | 14 x 6.7 x 15.2 in |
| Dimension note (imperial) | Standard tower orientation. |
| Compatible displays | All HP Z Displays and HP DreamColor Displays are supported. For more information see www.hp.com/go/zdisplays |
| External drive bays | One slim ODD; One 5.25" ODD |
| Internal drive bays | One 2.5" HDD; Two 3.5" HDD; Three M.2 NVME 2280 SSD |
| Internal Storage | 512 GB HP Z Turbo Drive PCIe® Gen4 TLC M.2 SSD |
| Storage controller | Integrated SATA (4 ports 6 Gb/s) with integrated RAID 0, 1, for PCIe SSDs supported. Requires identical hard drives (speeds, capacity, interface). |
| Energy Usage CO2e (kg) | 237 |
| Sustainable impact specifications | 80 Plus® Gold power supplies available; Bulk packaging available; Molded paper pulp cushion inside box is 100% sustainably sourced and recyclable; 45% post-consumer recycled plastic; 10% ITE-derived closed loop plastic; Low halogen PCAs; Product Carbon Footprint; Ocean-bound plastic in system fan, processor fan and speaker |
| End of Life CO2e (kg) | 2 |
| Production CO2e (kg) | 222 |
| Total CO2e (kg) | 460 |
| Total CO2e (kg) note | A product carbon footprint is defined as the total amount of greenhouse gases emitted directly and indirectly by a product over its lifetime. Greenhouse gas emissions are reported as global warming potential for 100-year time horizon (GWP-100) in units of CO2 equivalence. Calculations are done in accordance with ISO 14040 & ISO 14044. Individual values may not sum to total due to rounding. |
| Transportation CO2e (kg) | 2 |
| Graphics (integrated) | Intel® UHD Graphics 770 |
| Graphics | Integrated |
| Graphics (discrete) | NVIDIA RTX™ A2000 (6 GB GDDR6 dedicated) |
| Graphics | Discrete |
| Memory layout (slots & size) | 1 x 16 GB |
| Memory Slots | 4 DIMM |
| Memory | 16 GB DDR5-4800 MT/s non-ECC (1 x 16 GB) |
| Standard memory note | Transfer rates up to 4800 MT/s. |
| Memory and storage | 16 GB memory; 512 GB SSD storage |
| Audio | Realtek ALC3205-VA2-CG, 2.0W internal mono speaker |
| Keyboard | HP Wired Desktop 320K Keyboard |
| Pointing device | HP Wired 320M Mouse |
| Chipset | Intel® W680 |
| Processor cache | 33 MB L3 cache |
| Processor core | 20 |
| Processor family | Intel® Core™ i7 14th generation processor |
| Processor | Intel® Core™ i7-14700 (up to 5.4 GHz with Intel® Turbo Boost Technology, 33 MB L3 cache, 20 cores, 28 threads) |
| Security management | HP Secure Erase; HP Sure Click; HP BIOSphere Gen6; HP Sure Admin; Hood Sensor Optional Kit; HP Client Security Manager Gen6; HP Sure Start Gen7; HP Sure Recover Gen4; HP Sure Sense Gen2; HP Sure Run Gen5 |
| Security management | HP Tamper Lock |
| Security Software Licenses | HP Wolf Pro Security Edition (1 year) |
| Security software licenses footnote number | [56] |
| Management features | HP Driver Packs; HP Management Integration Kit for Microsoft System Center Configuration Management Gen4; HP System Software Manager (download); HP BIOS Configuration Utility (download) |
| Manageability Features 1 | HP Client Catalog (download) |
| Manageability Features 2 | HP Image Assistant (download) |
| Manageability Features 3 | HP Cloud Recovery |
| Manageability Features 4 | HP Client Management Script Library (download) |
| Software included | HP Support Assistant; HP PC Hardware Diagnostics Windows; HP Image Assistant; HP Manageability Integration Kit; Performance Advisor 3.0 |
| Software included | HP Notifications |
| Software included | HP Desktop Support Utilities |
| Software included | HP Documentation |
| Software included | myHP |
| Software included | WPS Office |
| Software included | HP Privacy Settings |
| Software included | Touchpoint Customizer for Commercial |
| Software included | HP UEFI BIOS Certification Level 2.7B |
| Operating system | Windows 11 Pro |
| Manufacturer Warranty | 3 year (3/3/3) limited warranty includes 3 years of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
| Weight | Starting at 6.2 kg |
| Weight note (metric) | Exact weight depends on configuration. |
| Package weight | Starting at 9.83 kg |
| Package weight | Starting at 21.65 lb |
| Weight | Starting at 13.7 lb |
| Weight note (imperial) | Exact weight depends on configuration. |
